Mining Machinery Mining Equipment Auxiliary Transport Charming Indestructible Transporter

Basic Info

Warranty	1 Year
Color	Yellow
Customized	Customized
Condition	New
After-sales Service	Service Machinery Overseas
Loading Capacity	1000 Kg
Max Load Capacity	3000 Kg
Traveling Speed	0~3 Km/H
Engine Power	26 Kw
Weight	2600 Kg
Size	3200*1200*1850 mm
Max. Traction	42
Operation Method	Two-Way Driving
Noise	Less 90 dB (a)
Min.Turning Radius	Less 1.75 M
Start Method	Explosion-Proof Electric Start
Cylinder Number of Engine	4
Transport Package	Wooden
Specification	5t
Trademark	Jikai
Origin	Shijiazhuang Hebei China
HS Code	8430412200
Production Capacity	1000sets/Year

Product Description

JIKAI Technology Company is ProfessionalManufacturer of Underground Mining Equipment

Explosion-Proof Diesel Crawler TransporterProduct Introduction:WCL sereis explosion-proof diesel crawler transporter is driven by explosion-proof engine, which is used for underground material transportation.We produced 3 types:WCL1Y,WCL3Y,WCL5Y.It's especially suitable for narrow laneway.

Main Features:
√ Full hydraulic driving, reliable , simple and accurate.
√ Crawler-mounted, ground pressure less than 0.06MPa, adapted to soft ground transportation.
√ Compact design, passing space 1200mm (optional 1100mm), good for narrow tunnel.
√ Bi-directional driving,more efficient.
√ Mounted with crane,lift up 1000kg material.

Parameters:

Detail	WCL1Y	WCL3Y	WCL5Y
Rated Loading Capacity(kg)	1000	3000	5000
Max. Loading Capacity(kg)	3000	5000	7000
Max. Traction (kN)	42	53	53
Traveling Speed(km/h)	0-3	0-4	0-4
Rated Engine Power(kW)	60	90	90
Weight(kg)	3000	5000	5000
Dimension(mm)	3260x1200x1800	4000x1400x1935	4000x1400x1935

At present, our company has built an advanced R&D system:Since 2007, the company has realized the network and digitization of R&D and design work;3D solid design and finite element analysis;Implemented product data lifecycle management (PLM);project workflow management; the integration of PLM system and ERP system;the paperless application of drawings and all technical data.
For example: 3D integral casting scraper conveyor not only greatly improves the service life of the scraper, but also promotes the intelligent construction of fully mechanized mining;Anti-gas and anti-groundpressure automatic drilling rig, equipped with remote control and video monitoring system, with real-time data collection functions, with one-key drilling function and anti-stucking functions, suitable for groundpressure prevention;The national III standard explosion-proof diesel engine monorail crane locomotive realizes multi-point direct transportation of hydraulic supports (48T); the drilling and bolting jumbo can drill with one key, and realize the automatic construction of anchor rods and anchor cable holes.With firm determination and strong investment, our company has always improved the quality management system, and effectively implemented the quality management system of full participation, full responsibility, whole process control and continuous improvement.We vigorously improve the quality management level to ensure product quality,meet user requirements and be responsible for users.At present, our company has established an advanced quality assurance system.According to the continuously improving quality management requirements, the company has successively developed quality management software that meets the standard requirements, realizing automatic detection and controlling the whole process.All products have corresponding quality control standards, which are completed simultaneously with design drawings and processes, and are recorded in the information management system.

Each product is marked with a unique permanent laser identification code when it is submitted for inspection. The inspection items and records correspond to each identification code, which realizes:1. Unique product quality identification; 2. Traceability of product quality problems; 3. Lifelong responsibility for product quality; 4. The basis for improvement is accurate and sufficient, and the improvement effect is tracked in place.In recent years, we have been rated as Hebei Provincial Enterprise Technology Center, Shijiazhuang Coal Mining Machinery Engineering Technology Research Center, Hebei Coal Mine Safety Equipment Engineering Technology Research Center (in preparation), Hebei Coal Mine Safety Equipment Inspection and Testing Platform (in preparation), The public technology research and development platform for coal mining machinery and equipment of the Ministry of Commerce has been fully affirmed by relevant departments in terms of product research and development, quality inspection, engineering technology transformation, and public services.

In the future, the engineering laboratory will obtain income through technical patents and paid use of new products, undertaking technical engineering research and development tasks for coal mine safety equipment industry, government scientific research funding, technical training and technical services, etc. "The virtuous cycle operation mode, and strive to achieve the sustainable development of the laboratory.
